LSIP-82/2
Cod EAN 4007754059892
Air core coil, 0.82 mH, Ø 0.85 mm
Weatherproof and Robust Exciters/Resonators for music and voice reproductions via surfaces capable of vibrating. These resonators are simply screwed onto doors, cupboard doors, shelves, desktops, lightweight walls, ceiling panels or many other surfac...
Impedance (Z) | 8 Ω |
Frequency range | dep. on the installation |
Resonant frequency (fs) | 600 Hz |
Power rating (RMS) | 15 W |
Peak music power output (MAX) | 30 W |
SPL | no data |
Mounting cutout | not applicable |
Dimensions | Ø 80 mm x 40 mm |
Outside diameter | Ø 80 mm |
Width | Ø 80 mm |
Height | 40 mm |
Colour | black |
Protective class | IP68 |
Admiss. ambient temp. | -30 °C to +40 °C |
Weight | 0.425 kg |
Packing unit | 1 |
Packing dimensions (W x H x L) | 0.09 x 0.05 x 0.09 m |
Gross weight | 0.455 kg |
Net weight | 0.425 kg |
