ESP-1000AB

Cod EAN: 4007754263862

PA A/B wall speaker, with EN 54-24 certification for voice alarm systems with A/B speaker distribution according to EN 60849. 100 V transmission technology 2 x 10 cm full range speaker 2 separate transformers with power taps with 6/3/1.5 W each Co...

Citeste mai mult

Intreaba despre produs
Cumpara acum


ESP-1000AB

PA A/B wall speaker,
with EN 54-24 certification for voice alarm systems with A/B speaker distribution according to EN 60849.
  • 100 V transmission technology
  • 2 x 10 cm full range speaker
  • 2 separate transformers with power taps with 6/3/1.5 W each
  • Connection via 2 ceramic screw terminals inside the cabinet
  • Plastic cabinet with open rear panel with protective metal front grille
  • Supplied with aluminium mounting bracket, screws and wall plugs
Manufacturer information:
MONACOR INTERNATIONAL GmbH & Co. KG
Zum Falsch 36
28307 Bremen
Germany
info@monacor.com

Parametrii

Active/passive passive
Transmission technology 100 V
Total power rating 2 x 6 W
Power rating (RMS) 2 x 6/3/1.5 W
Frequency range 80-20,000 Hz
Full range speaker 2 x 10 cm
Number of speakers 2
Speaker size 10 cm (4")
SPL 2 x 92 dB (1 W/1 m) 76 dB (EN, 1 W/4 m)
Max. rated SPL 2 x 100 dB (1 m) 85 dB (EN, 4 m)
Radiation angle/beam angle 180° (500 Hz) 180° (1,000 Hz) 130° (2,000 Hz) 95° (4,000 Hz)
Radiation angle, horizontal 180° (500 Hz), 180° (1,000 Hz), 130° (2,000 Hz), 95° (4,000 Hz)
Radiation angle, vertical 180° (500 Hz), 180° (1,000 Hz), 130° (2,000 Hz), 95° (4,000 Hz)
Housing material metal
Colour white
Mounting device bracket
Admiss. ambient temp. -10 °C to +50 °C
Dimensions Ø 220 mm x 100 mm
Width Ø 220 mm
Height Ø 220 mm
Depth 100 mm
Weight 1.98 kg
Inputs ceramic screw terminals
Packaging dimensions (W x H x L) 0.235 x 0.125 x 0.235 m
Gross weight 2.126 kg
Net weight 1.986 kg

Fisiere de descarcat

Fisa produsului ESP-1000AB konformitaetserklaerung-ce konformitaetserklaerung-ukca Manual de utilizare
