EDL-310L
Cod EAN 4007754206562
Super dispersion PA ceiling speaker
Weatherproof PA speaker system with 20 cm (8") coaxial horn speaker, developed for outdoor applications, with an excellent sound quality. The SL-150SW/EN is ideally suited for applications at versatile locations, e.g. airports, megastores and stadium...
Active/passive | passive |
Transmission technology | 100 V or low-impedance |
Total power rating | 150 W |
Power rating (RMS) | 150/75/38 W |
Impedance | 8 Ω |
Frequency range | 90-19,000 Hz |
System | 2-way coaxial |
Bass speaker | 20 cm (8") |
Tweeter | tweeter |
Number of speakers | 2 |
Speaker size | 20 cm (8") |
SPL | 98 dB/W/m |
Max. rated SPL | 120 dB |
Radiation angle/beam angle | H: 80°/V: 80° |
Radiation angle, horizontal | 80° |
Radiation angle, vertical | 80° |
Housing material | ABS |
Colour | black |
Mounting device | mounting bracket |
Protection class | IP66 |
Admiss. ambient temp. | -25 °C to +70 °C |
Dimensions | 315 x 305 x 350 mm |
Width | 315 mm |
Height | 305 mm |
Depth | 350 mm |
Weight | 11.85 kg |
Inputs | screw terminal |
Packaging dimensions (W x H x L) | 0.39 x 0.47 x 0.39 m |
Gross weight | 13.9 kg |
Net weight | 11.85 kg |
