TS-C10-300/T

Cod EAN: 4260590180483

Weatherproof PA column speaker, with EN 54-24 certification. 100 V transmission technology 2 x 7.7 cm (3") waterproof full range speaker 4 power taps: 10/6/3/1.5 W Connection via ceramic terminals with thermal fuse in the cabinet 2 x PG9 cable glan...

Citeste mai mult

Intreaba despre produs
Cumpara acum


TS-C10-300/T

Weatherproof PA column speaker,
with EN 54-24 certification.
  • 100 V transmission technology
  • 2 x 7.7 cm (3") waterproof full range speaker
  • 4 power taps: 10/6/3/1.5 W
  • Connection via ceramic terminals with thermal fuse in the cabinet
  • 2 x PG9 cable gland
  • Robust, plastic-coated aluminium cabinet with front protective grille
  • The speaker complies with British Standard BS 5839, part 8
  • Supplied with plastic wall bracket for pivoting and tilting
Manufacturer information
ic audio GmbH
Boehringerstr. 14a
68307 Mannheim
Germany
info@ic-audio.com

Parametrii

Active/passive passive
Transmission technology 100 V
Total power rating 10 W
Power rating (RMS) 10/6/3/1.5 W
Frequency range 200-18,000 Hz
Full range speaker 2 x 77 mm
Number of speakers 2
Speaker size 7.5 cm (3")
SPL 95 dB/W/m
Max. rated SPL 104 dB
Radiation angle/beam angle H: 149°/V: 66°
Radiation angle, horizontal 149°
Radiation angle, vertical 66°
Housing material aluminium
Colour white aluminium, RAL 9006
Mounting device wall bracket
Protection class IP66
Admiss. ambient temp. -20 °C to +90 °C
Dimensions 100 x 296 x 92 mm
Width 100 mm
Height 296 mm
Depth 92 mm
Weight 1.6 kg
Inputs ceramic screw terminals
Packaging dimensions (W x H x L) 0.175 x 0.19 x 0.37 m
Gross weight 2.06 kg
Net weight 1.758 kg

Fisiere de descarcat

Fisa produsului TS-C10-300/T
