PAK-415

Cod EAN: 4007754244908

PAK-400 Series The PAK-400 series is suitable for general applications, features modern technologies and an individual sound tuning to meet various requirements. The amplifier system is a combination of class D for the bass and class A/B for the twee...

Citeste mai mult

Intreaba despre produs
Cumpara acum


PAK-415

PAK-400 Series
The PAK-400 series is suitable for general applications, features modern technologies and an individual sound tuning to meet various requirements. The amplifier system is a combination of class D for the bass and class A/B for the tweeter. With practice-oriented presets, it is easy to find the perfect sound and with the high-pass filter to be activated as required at 75 Hz, this series can easily be matched to subwoofer systems like the PSUB-418AK.
Active power PA speaker system with 2-channel amplifier, 700 W
  • Compact 15/2 full range system with robust plastic cabinet
  • Modern amplifier system (bass: class D, tweeter: class A/B)
  • Sound pressure at nominal power: 124 dB
  • 4 selectable presets: normal, hi-fi, DJ and voice, switchable high-pass filter: 75 Hz
  • Mic/line input, switchable
  • LED indicators for power, signal and peak/clipping
  • M10 threaded inserts (2 x top, 2 x bottom, 1 x at the rear)
  • Bevelled side for application as a floor monitor
  • Stand sleeve and carrying handles
TASTENWELT 06/2015
“The PAK-400 series from IMG Stage Line features individual adjustment facilities using modern technology which makes it suitable for most versatile applications; definitely a concept that works: this series provides a perfect system for everyone, including keyboard entertainers, combinations of entertaining music and DJs.”

Parametrii

Active/passive active
Transmission technology cable
Total output power 700 W
Power rating (RMS) 450 (350+100) W
Frequency range 40-20,000 Hz
Input signal 260 mV/10 kΩ (line),2 mV/10 kΩ (mic)
System 15/2 full range
Bass speaker 38 cm (15") bass speaker
Tweeter 33 mm (1.3") tweeter
Number of speakers 2
Speaker size 38 cm (15")
SPL 98 dB/W/m
Max. rated SPL 124 dB
Radiation angle/beam angle H: 100°/V: 70°
Radiation angle, horizontal 100°
Radiation angle, vertical 70°
Housing material plastic
Colour black
Mounting device M10 threaded inserts, stand sleeve
Admiss. ambient temp. 0-40 °C
Power supply ˜ 230 V/50 Hz/550 VA
Dimensions 455 x 740 x 390 mm
Width 455 mm
Height 740 mm
Depth 390 mm
Weight 18.7 kg
Inputs 1 x comb. XLR/6.3 mm (line/mic)
Outputs 1 x XLR, par. out
Other features 4 selectable presets switchable high-pass filter: 75 Hz
Packaging dimensions (W x H x L) 0.48 x 0.84 x 0.54 m
Gross weight 21.82 kg
Net weight 19.16 kg

Fisiere de descarcat

Fisa produsului PAK-415 konformitaetserklaerung-ce konformitaetserklaerung-ukca Manual de utilizare Manual de utilizare
