WAVE-10P
Cod EAN: 4007754274028
Pure Entertainment! The PA speaker systems of the WAVE series impress with a great sound and an attractive price. They are suitable for smaller to medium-sized function rooms and are the perfect starting equipment for entry-level DJs. The plastic cab...
WAVE-10P
Pure Entertainment!
The PA speaker systems of the WAVE series impress with a great sound and an attractive price. They are suitable for smaller to medium-sized function rooms and are the perfect starting equipment for entry-level DJs. The plastic cabinets of contemporary design are also lightweight and easy to use. Thus, they are ideally suited for mobile applications.
Passive full range speaker system, 300 W, 8 Ω
- Full range bass-reflex system
- Robust plastic cabinet
- 25 cm (10") bass speaker with steel basket
- 25 mm (1") horn tweeter, 25 mm (1") voice coil diameter
- PTC tweeter protection
- M8 threaded inserts at the top and bottom
- 2 x SPEAKER jack, in/out
- Stand sleeve
Manufacturer information:
MONACOR INTERNATIONAL GmbH & Co. KG
Konsul-Smidt-Str. 68
28217 Bremen
Germany
info@monacor.com
Konsul-Smidt-Str. 68
28217 Bremen
Germany
info@monacor.com
Parametrii
| Active/passive | passive |
| Transmission technology | cable |
| Total power rating | 300 W |
| Power rating (RMS) | 150 W |
| Impedance | 8 Ω |
| Frequency range | 60-20,000 Hz |
| System | 10/2 full range bass-reflex |
| Bass speaker | 25 cm (10") bass speaker |
| Tweeter | 25 mm (1") horn tweeter |
| Number of speakers | 2 |
| Speaker size | 25 cm (10") |
| SPL | 95 dB/W/m |
| Max. rated SPL | 117 dB |
| Radiation angle/beam angle | H: 90°/V: 60° |
| Radiation angle, horizontal | 90° |
| Radiation angle, vertical | 60° |
| Housing material | plastic |
| Colour | black |
| Mounting device | M8 threaded inserts, stand sleeve |
| Admiss. ambient temp. | 0-40 °C |
| Dimensions | 300 x 510 x 210 mm |
| Width | 300 mm |
| Height | 510 mm |
| Depth | 250 mm |
| Weight | 7.5 kg |
| Inputs | 1 x SPEAKER |
| Outputs | 1 x SPEAKER, par. out |
| Packaging dimensions (W x H x L) | 0.31 x 0.35 x 0.565 m |
| Gross weight | 8.43 kg |
| Net weight | 7.54 kg |
